Tensile Strength Tester

Name: Tensile Strength Tester
Brand: GLOBE ENTERPRISES
Price: 125000 INR
Availability: InStock

Price 125000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Tensile Strength Tester Specification

Response Time
Instantaneous

Port Size
Standard clamp design

Features
Digital display, Overload protection, Auto calibration

Temperature
10C~35C

Display Type
Digital LCD

Max Height
700 mm

Equipment Type
Tensile Strength Tester

Power Supply
220V AC, 50Hz

Specimen Size
As per standards (ASTM/DIN/IS/ISO)

Accuracy
1%

Interface Type
RS232/USB

Resolution
0.01 mm

Application
Paper, Plastic, Rubber, Textile, Film testing

Measuring Range
up to 5000 N

Frequency
50 Hz

Operating Voltage
220V

Number of Specimens
1 at a time

Humidity
20%~80% RH

Usage
Material strength testing

Capacity
5 kN, 10 kN (options available)

Machine Weight
Approx. 50 kg

Test Width
100 mm

Test Stroke
Up to 700 mm

Control Mode
Digital microprocessor based

Accessories Included
Sample grips, User manual, Calibration certificate

Gripping Mechanism
Manual / Pneumatic (Options)

Finish
Powder coated, Rust resistant body

Data Output
Direct data print and PC connectivity

Operation Mode
Motorized, Push button controls

Compliance
ASTM D638, IS 13934, ISO 527

Memory Function
Stores up to 200 test results

Load Cell Type
High precision strain gauge type

Tensile Strength Tester Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Units Per Month

Delivery Time
15 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ISO Certified

About Tensile Strength Tester

Tensile Strength Tester

We have achieved high acclamation in the industry for offering a top-of-the-line gamut of Tensile Strength Tester. Manufactured as per industrial standards using quality components, these testing equipments are known for their high efficiency and accuracy. We are offering these testing equipments to our clients without any delay. Our offered Tensile Strength Tester is easy to use and widely used to determine the elongation & tensile strength of variety of raw materials such as fabrics, wires, leather, plastics, belts and rubbers.

Further details:

Tensile strength and elongation are the two prime characteristics of most of the raw materials, . These two properties often play a major role in determining the suitability of any raw material for any specified application. It is, therefore, of utmost importance to determine these characteristics accurately, conveniently, and quickly.

Technical specification

Material	Stainless Steel
Voltage	220 V
Frequency	50 Hz
Brand	Globe Enterprises

High-Precision and Durability

Equipped with a strain gauge load cell and advanced digital microprocessor controls, the tester delivers high-precision measurements with 1% accuracy across a measuring range up to 5000 N. Its powder-coated, rust-resistant body ensures long-term durability, while overload protection enhances reliability.

Versatile Application and Compliance

Designed for testing a variety of materialsincluding paper, plastic, rubber, textiles, and filmsthis tensile tester meets ASTM D638, IS 13934, and ISO 527 standards. The adjustable specimen size capability and options for manual or pneumatic grips make it highly adaptable.

User-Friendly Operation and Data Handling

With user-friendly push-button controls, a clear digital LCD display, and instant response, this tester streamlines the testing process. Data can be output directly to a printer or PC for analysis, and the built-in memory stores up to 200 tests, supporting efficient workflow.

FAQs of Tensile Strength Tester:

Q: How do you operate the Tensile Strength Tester for material testing?

A: To operate the Tensile Strength Tester, secure the specimen using the appropriate grips (manual or pneumatic), select settings using the digital microprocessor-based controls, and initiate the test with the push-button interface. The results are displayed instantly on the digital LCD and can be exported via direct print or PC connectivity.

Q: What types of materials can be tested with this tensile tester?

A: This equipment is suitable for testing tensile properties of materials such as paper, plastic, rubber, textiles, and films. It accommodates specimens as per international standards including ASTM, DIN, IS, and ISO.

Q: When should the tester be recalibrated, and is auto-calibration available?

A: For optimal accuracy, periodic recalibration is recommended as per laboratory protocols or after extensive use. The tester features an auto calibration function, simplifying the recalibration process and maintaining measurement precision.

Q: Where can the test results be saved, and how much data can be stored?

A: Test outcomes can be directly printed or saved to a connected PC via RS232/USB interface. The internal memory is capable of storing up to 200 individual test results for later retrieval or analysis.

Q: What is the benefit of the powder-coated, rust-resistant finish?

A: The powder-coated and rust-resistant finish protects the tester from environmental factors such as humidity (20%~80% RH) and temperature variations (10C~35C), ensuring long-term durability and consistent performance.

Q: How does the digital control mode improve the testing process?

A: The digital microprocessor-based control mode ensures precise test execution, easy parameter setting, accurate readings, and advanced features like overload protection and instantaneous data response, which improve efficiency and safety.
